Page 37
BeWa CS1000 3247149k en.doc 2006-04-06
Mode 3 (M3) Switching output CLOSED Switching output OPEN
Measurement is currently in progress
and one or more of the last 5
measured values > limit
5 consecutive measured values ≤ limit
or measurement stopped
Mode 4 (M4) Switching output CLOSED Switching output OPEN
Start or result of
check
measurement after
test cycle time ≥
upper limit
Measurement is currently in progress
and one or more of the last 5
measured values > limit
5 consecutive measured values ≤ limit
or measurement stopped
Upon the test cycle
time elapsing for
the duration of a
check
measurement
Test cycle time has elapsed
Opens again when measured value <
upper limit
Restart test cycle time
Single Mode
(SINGLE)
Switching output CLOSED Switching output OPEN
— Always open
9 Analog Output (ANaOUT)
The analog output is available as a 4 – 20 mA or 0 – 10 V DC signal.
The following signals can be selected in the measurement menu:
9.1 SAE Classes
The following SAE values can be output via the analog output:
• SAE A-D (
SAEMAX)
Only a single value is output (see section 9.1.2).
• SAE A / B / C / D
All values are sequentially output time-coded (see section 9.1.3).
• SAE A / SAE B / SAE C / SAE D
Only one value is output (see section 9.1.4).
• SAE + T
All values are sequentially output time-coded (see section 9.1.5).
