Tecnical Data / Model code
HYDAC Filtertechnik GmbH
en
Page 73
BeWa CS1000 3247149k en.doc 2006-03-14
Electrical data
Connection plug M12x1, 8 pole, male,
specified in DIN VDE 0627 resp. IEC61984
Power supply voltage 9 ... 36 V DC, residual ripple < 10%
Power consumption 3 Watt max.
Analog output 4 conductor technology
4 ... 20mA active output (max. burden 330Ω) or
0 ... 10 V active output (min. load resistor 820Ω)
Switching Output passive, n-switching Power MOSFET:
max. current 1,5 A, normally open
RS-485 Interface 2 wire, half duplex
HYDAC Single Wire interface For HMG 3000 use only
19 Service
Shipping Address for Recalibration and Repair Work
HYDAC Servicenter GmbH
Rehgrabenstrasse, Werk 7
66121 Saarbrücken, Germany
Phone: ++49 (0)681 509 - 01
