INSTALLATION
INTERNAL STRUCTURE
1 Touch screen
2 RFID card reader
3 LED indicator lights
4 OCPP
5 Door locks
6 MID Relay x 2
7 Auxiliary power supply
8 MID Meter x 2
9 Contactor x 2
10 Type B RCD x 2
11 Power cable
1
2
3
14
5
6
7
8
9
10
11
