14
INSTALLATION
SITE SPACE REQUIREMENTS
Adequate installation space should be reserved to ensure safe and reliable operation, ventilation and
maintenance of the equipment.
Installation requires 1386 x 900 mm of space, calculated as follows:
Product size: 400(L) X 386(W) X 1500*(H) , excluding cable hangers and accessories. *TBC
Front reserved spacing ≥400mm to ensure the front door open/close operation is normal and all related
operations are unhindered.
Left reserved spacing ≥ 500mm to ensure operating space.
Right-hand reserved spacing ≥ 500mm to ensure operating space.
Rear reserved spacing ≥ 100mm to ensure operating space.
Dimensions (from above)
400mm
386mm
