Hydra GENESIS - TECHNICAL SPECIFICATIONS

✆ 01268 205 121 | www.hydraev.co.uk | sales@hydraev.co.uk
8
INTRODUCTION
TECHNICAL SPECIFICATIONS
COMPONENT
SPECIFICATIONS
Dimensions 280(W) x 190(L) x 1500(H)* mm *TBC
Weight 53kg (including cable)
Cable length ≥4.2m/SOCKET
Shell material Sheet metal
Screen 5” LCD touch screen
POWER
CHARACTERISTICS
Input voltage
TN-S 240V AC (single phase)
400V AC (three phase) ±10%
Input frequency 50hz/60hz
Rated power
7kW (single phase)
22kW/43kW (three phase)
Measurement accuracy ≤±0.5%
Output voltage Same as input voltage
Output current 7kW/22kW-32A, 43kW-63A
Efciency ≥94%
Factor ≥0.99
DESIGN FEATURES
UI RFID Card Reader, LCD touch screen
Standard GB/T, TYPE1 J1772, TYPE2 and IEC61851-1/2017
COMMUNICATION
Web interface Wired Ethernet, Wi-Fi, 3G/4G
OCPP OCPP 1.6J
