Page 11-5: Machine Assemblies and Parts List
Boxxer 421
Item Part Number Description Qty
Frame Assembly Parts List
1 000-055-149 Frame, Weldment - Boxxer 421 1
2 000-015-752 Bracket, Muffler Mounting 1
3 000-015-745 Bracket, Coil Heat Exchanger Saddle - Boxxer 421 1
4 000-015-758 Bracket, Exhaust Support 1
5 000-169-064 Valve, 3/8" NPT Full Port Ball 1
6 000-001-098 Adapter, Exhaust Turndown - Weldment 1
7 Fig. 11-24 Assembly, By-Pass Valve - Boxxer 421 1
8 Fig. 11-23 Assembly, Hi-PSI Manifold - Boxxer 421 1
9 000-052-052 Quick Connect, 660 Male w/ Viton Standard 1
10 000-052-051 Quick Connect, 440 Female w/ EPDM O-Ring 1
11 000-143-126 Screw, #10-24UNC x 0.50" Lg. Hex Head 13
12 000-143-542 Screw, 1/4"-28UNF x 0.50" Lg. 2
13 000-174-007 Washer, 1/2" Flat 2
14 000-174-008 Washer, 5/8" Flat 3
15 000-174-030 Washer, 5/8" I.D. x 7/8" O.D. x 0.010" Thk. 1
16 000-052-090 Tee, 1/4" NPT Branch M-F-F 1
17 000-052-532 Elbow, 1/4" SAE x 1/4" JIC x 90° 1
18 000-052-073 Nipple, 3/8" NPT x 1/4" NPT Hex 1
19 000-169-177 Valve, 3/8" FPT Check 65 PSI 1
20 000-052-528 Nipple, 3/8" M JIC x 3/8" NPT 1
21 000-060-002 Grommet, Large Wiring 1
22 000-060-013 Grommet, 3/4" Id x w/ 1/8" Groove 1
23 000-033-057 Clamp, 1" Cushion Loop 8
24 000-033-046 Clamp, 1/2 Wide x 1/2 Tube 3
25 000-033-053 Clamp, 1-1/2" Cushion Loop 4
26 000-060-010 Grommet, 1-5/16" I.D. 1
27 000-157-012 Switch, Starter Solenoid 14 HP B&S 1
28 000-033-067 Clamp, 2" Cushion Loop 2
29 000-108-115 Protector, 5/8" Bumper 8
30 000-174-001 Washer, #10 Flat 14
