Page 11-6: Machine Assemblies and Parts List
Boxxer 421
Frame Assembly Parts List
Item Part Number Description Qty
31 000-174-049 Washer, 5/16" Flat 10
32 000-174-018 Washer, 5/16" Lock 6
33 000-094-012 Nut, 5/16-18"UNC Hex 4
34 000-143-143 Screw, 5/16"-18UNC x 1.00" Lg. Hex Head 2
35 000-143-132 Screw, #10-24UNC x 0.75" Lg. Hex Head 3
36 000-094-034 Nut, #10-24UNC Nylock 4
37 000-174-003 Washer, 1/4" Flat 4
38 000-094-009 Nut, 1/4"-20UNC Hex Nylock 4
39 000-174-014 Washer, #10 Lock 2
40 000-052-075 Nipple, 3/8" NPT x 1/2" NPT 1
41 000-052-104 Insert, #66 (3/8" NPT x 3/8" Barb) 1
42 000-163-056 Magnaclean, Hard Water Protector - Complete 1
43 000-033-050 Clamp, 1-3/4" Cushion Loop 1
44 000-052-107 Insert, #88 (1/2" NPT x 1/2" Barb) 1
45 000-143-094-1 Screw, 3/8"-16UNC x 0.75" Lg. Socket Head 2
46 000-033-116 Clamp, 1-1/2" Cushion Loop w/ 7/16" Mounting Hole 1
47 000-033-023 Clamp, 3/4" Nylon Hose 1
48 000-154-125 Spacer, Frame Tube Removable - Boxxer 421 1
49 000-033-123 Clamp, After Burner Mount - Boxxer 421 1
50 000-141-033 Rod, Heat Exchanger Strap - Retainer 2
51 000-143-017 Screw, 3/8"-16UNC x 3/4" Lg. Hex Head 2
52 000-143-316 Screw, 5/16"-18UNC x 2.00" Lg. Hex Head 1
53 000-094-081 Nut, 5/16"-18UNC Hex 2-Way Locking 1
54 000-052-083 Elbow, 3/8" NPT Street x 45° 1
55 000-057-055 Gasket, Garden Hose 1
56 000-056-006 Fuse Holder, Inline Weather Proof 1
57 000-106-040 Plug, Frame End 4
58 000-056-011 Fuse, 30 AMP Plug In 1
59 000-052-105 Insert, #68 (3/8" NPT x 1/2" Barb) 1
