HydraMaster Boxxer 421 - Electrical Control Panel Assembly Parts List

HydraMaster Corporation
Page 11-14: Machine Assemblies and Parts List
Boxxer 421
Item Part Number Description Qty
Electrical Control Panel Assembly Parts List
1 000-100-113 Panel, Electrical Control - Boxxer 421 1
2 000-041-377 Cover, Electrical Panel - Boxxer 421 1
3 000-074-125 Controller, Temp. Single Analog RTD Input 1
4 000-012-010 Block, Terminal 10 Post 1
5 000-157-022 Switch, Relay 6
6 000-094-034 Nut, #10-24UNC Nylock 12
7 000-060-002 Grommet, Large Wiring 4
8 000-056-020 Fuse Panel 1
9 000-084-010 Light, Green LED Indicator Mini 1
10 000-084-011 Light, Red LED Indicator Mini 1
11 000-033-066 Clamp, 3/4" Spring 2
12 000-033-023 Clamp, 3/4" Nylon Hose 1
13 000-174-001 Washer, #10 Flat 8
14 000-143-126 Screw, #10-24UNC x 0.50" Lg. Hex Head 3
15 000-156-030 Stud, #10-32UNF x 2" Lg. Boxxer Elec. Panel Cover 2
16 000-094-108 Nut, #10-32UNF Wing 2
17 000-084-012 Light, Yellow Led Indicator Mini 1
18 000-143-111 Screw, #10-24UNC x 0.25" Lg. Set 2
19 000-174-014 Washer, #10 Lock 4
20 000-143-545 Screw, #8-32UNC x 1.00" Lg. Phillips Head 4
21 000-154-111 Spacer, Electrical Panel - Boxxer 421 1
22 000-174-019 Washer, 1/4" Lock 2
23 000-174-003 Washer, 1/4" Flat 2
24 000-143-080 Screw, 1/4"-20UNC x 1.00" Lg. Socket Head 2
25 000-131-027 Trimlok, 3/8" Wrinkled 1
26 000-094-058 Nut, #10-32 UNF - Nylock 2
