HydraMaster Boxxer 421 - Exhaust Assembly Parts List

Page 11-27: Machine Assemblies and Parts List
Boxxer 421
Exhaust Assembly Parts List
Item Part Number Description Qty
1 000-169-045 Valve, Cast Exhaust Diverter 1
2 000-038-054 Core, Boxxer 421 After Burner Heat Exchanger - Weldment 1
3 000-125-152 Tube, Muffler Outlet - Boxxer 421 1
4 000-093-081 Muffler Exhaust Modified - Boxxer 421 1
5 000-001-099 Adapter, Exhaust Flange To Ø1.50" F Slip - Boxxer 421 1
6 000-052-703 Elbow, Exhaust Manifold To Diverter - Boxxer 421 1
7 000-041-397 Cover, Exhaust - Boxxer 421 1
8 000-015-764 Bracket, Exhaust Cover Mounting 1
9 000-052-600 Elbow, 1/2" Tube x 3/8" FPT 2
10 000-094-027 Nut, #10-24UNC Hex 2
11 000-155-030 Spring, Leaf 1
12 000-138-010 Retainer, Leaf Spring 1
13 000-174-001 Washer, #10 Flat 2
14 000-143-132 Screw, #10-24UNC x 0.75" Lg. Hex Head 2
15 000-015-631 Bracket, Air Cylinder Actuation 1
16 000-103-005 Pin, Roll - 0.125" x 0.500" Lg. 1
17 000-057-146 Gasket, Four Hole Exhaust Diverter 3
18 000-052-528 Nipple, 3/8" M JIC x 3/8" NPT 2
19 000-001-102 Adapter, Exhaust Flange To 1.50" M Slip 1
20 000-033-068 Clamp, 1-1/2" Muffler 3
21 000-143-001 Screw, 1/4"-20UNC x 0.75" Lg. Hex Head 4
22 000-174-003 Washer, 1/4" Flat 4
23 000-174-019 Washer, 1/4" Lock 4
24 000-174-069 Washer, 5/16" Inconel Belleville, Diverter Valve 12
25 000-143-572 Screw, 5/16"-18UNC x 5/8" Lg. Hex Grd. 5 12
26 000-125-128 Tube, 1-3/8" Od x 1/8" Wall x 7/8" Long 2
27 000-057-177 Gasket, Exhaust Donut 1.50" 2
28 000-143-124 Screw, 5/16"-18UNC x 1.75" Lg. Hex Head 4
29 000-174-049 Washer, 5/16" Flat 14
30 000-094-081 Nut, 5/16"-18UNC Hex 2-Way Locking 10
31 000-106-120 Plug, M18 x 1.5 1
