Hydro-Smart 115 - Electrical Connections

Installation
21│Page
Followtheelectricalcoderequirementsofthelocalauthorityhaving
jurisdiction.Intheabsenceofsuchrequirements,followthelatesteditionof
theNationalElectricalCodeANSI/NFPA70intheU.S.orthelatesteditionof
CSAC22.1CanadianElectricalCode,Part1,inCanada.
Whenservicingorreplacingpartswithinthewaterheater,labelallwires
priortodisconnectiontofacilitateaneasyanderror‐freereconnection.
Wiringerrorscancauseimproperanddangerousoperation.Verifyproper
operationafterservicing.

ELECTRICALCONNECTIONS
Theindoormodelcomeswithapowerpluginsteadofajunctionbox.Thefollowingprocedureisfor
outdoormodelsonly.
1. Thewaterheatermustbeelectricallygrounded.Donotattachthegroundwire toeitherthegasor
thewaterpiping.

2. Thewaterheaterrequires120VAC/60Hzelectricalpowersupplythatisproperlygrounded.
 A proper disconnect (i.e. on/off switch, power plug, etc.) controlling the main power to the
waterheatermustbeprovidedforservicereasons.(Mustcomplywithlocalcodes).
 Connectthepowersupply
tothewaterheaterexactlyasshowninthewiringdiagram;

3. Agreenscrewisprovidedinthejunctionboxtogroundtheconnection.
4. Canbehardwiredorwiredtoaplug‐in.
5. Theuseofasurgeprotectorisrecommendedinordertoprotecttheunit
frompowersurges.




















CAUTION
WARNING
Viewofelectricalconnectionsofwaterheater
Connect
Powersupply
120VAC/60Hz
Ground
Greenscrew
Outdoormodelonly
Bottomview
ofwaterheater
Indoormodelonly
