Page 15
5.1.1 Fitting
Wall Mounting
Note: To function properly the steam humidifier must be installed verti-
cally.
» Position the steam humidifier in the planned location,
adjust with spirit level and mark position of hanging
bolts.
» Hang the unit onto bolts screwed into the marked posi-
tion and tighten.
If there is no suitable wall, it is recommended that the equipment
is installed on brackets which can be embedded in the floor.
Note: The C45KIT cannot be used for wall mounting. The instal-
lation has to be done on brackets.
Wall Mounting
Note: To drain properly drain hose system of C17KIT until
C45KIT must be fixed straightly above bracket.
Warning: If the installation of this unit is attempted by only one
person there is a risk that the unit drops down. We propose to
carry out the installation by two persons.
