5.8 Condensate Hose
Note: When installing the condensate hose, please pay atten-
tion to the following:
Warning: To keep condensate from accumulating in the duct,
make sure condensate can drain freely.
If the steam manifold is positioned higher than 500 mm
above the steam humidifier:
» Remove the condensate plug (12) from the connection
fitting on the cylinde.
» Lay the condensate hose at an approximate incline of
5-10% to the steam cylinder connection fitting, to allow
the condensate to drain freely.
Note: It is recommended to form a loop of 200 mm diameter as
a vapour trap provided there is enough space.
If the steam manifold is positioned lower than 500 mm
above the steam humidifier:
» The condensate must be drained separately.
» To prevent steam loss, lay a loop at least 200 mm in di-
ameter.
» To ensure condensate drainage, place the loop (vapor
trap) as far away as possible below the steam manifold
connection.
» The condensate connection on the steam cylinder (16 +
19) must be closed with a sealing cap.
» Place hose clamps at intervals of at least 500 mm, de-
pending on how the hose is laid.
5.9 Types of Installation
The steam manifold is positioned higher than 200 mm
above the steam humidifier.
» Lay the steam hose at a height of at least 400 mm and
then connect to the steam manifold with a constant rise
or fall.
» Lay condensate hose with a slope to the steam cyl-
inder.
