8.4 Cleaning the Water Inlet Solenoid Valve
Removal
» Shut off water supply and loosen water installation hose
connection.
» Remove cylinder; please also see chapter „Removing
and Cleaning Steam Cylinder“
» Loosen connecting hose (21) from the base.
» Detach e-cable from the solenoid valve.
» Loosen solenoid valve mounting screws (28).
» Remove solenoid valve from the borehole.
» Remove fine mesh filter (29) from the solenoid valve,
clean and replace if needed.
Installation
» Insert fine mesh filter (29).
» Place solenoid valve with seal in the borehole of the
unit housing.
» Attach solenoid valve tightly with screws (28).
» Screw on water installation hose.
» Connect e-cable to the solenoid valve.
» Attach connecting hose (21) to the base.
» Install cylinder.
» Turn on the tap.
» Switch on the unit and check for leaks during operation.
If leakage occurs, switch off power supply and follow safety
instructions for work on live components.
