Page 38
HyLine:
CompactLine:
MiniSteam:
CompactLine KIT:
Other voltages are available on request.
We recommend employing quick or medium blow main fuses (ap-
plicable only to the grid voltages above). See table below indicat-
ing maximum power usage for each circuit protection:
HyLine:
Type Main Power Supply
HY05 - HY45 1 x 400V/3Phase/N
HY60 - HY116 2 x 400V/3Phase/N
Type Main Power Supply
CompactLine 1 x 400V/3Phase/N
Type Main Power Supply
MS5
MS10
1 x 400V/3Phase/N
MS5 1 x 230/1Phase/N
Type Main Power Supply
C01KIT, C02KIT 1 x 230V/1Phase
C06KIT - C45KIT 1 x 400V/3Phase/N
Type Power Usage Circuit Protection
HY05 5,4 A 3 x 6A
HY08 8,7 A 3 x 10A
HY13 14,1 A 3 x 16 A
HY17 18,4 A 3 x 20 A
HY23 24,9 A 3 x 35 A
HY30 32,5 A 3 x 35 A
HY45 48,8 A 3 x 63 A
HY60 2 x 32,5 A 6 x 35 A
HY90 2 x 48,8 A 6 x 63 A
HY116 2 x 62,8 A 6 x 63 A
