Page 47
» Remove and open cylinder, as described in Section
"Removing and Cleaning Steam Cylinder."
» Loosen knurled nuts (5) and remove electrodes (48).
» Install new electrodes and hand tighten the nuts.
» Use solvent-free, HygroMatik-quality o-rings (for flange,
cylinder base and steam hose adapter).
» Assemble steam cylinder and place it into cylinder
» Connect plugs (4) directly to the electrodes (48) (with
gray, red and black knurled nuts). It is not necessary to
detach the knurled nuts!
Warning: The plug must be pressed down onto the electrode as
far as it will go.
Note: Connect plugs to the correct electrodes. Pay attention to
the color of the knurled nut.
» Attach plug (8) to the sensor electrode. (Knurled nut (9)
- gray)
» Switch breaker back on.
» Switch on the unit and check for leaks after 15-30 min-
utes of operation.
If leakage occurs, switch off power supply and follow safety
instructions for work on live components.
Note:
In the following cases:
• the electrodes must be frequently replaced,
• black slime collects inside the cylinder, or
• there is "lightning" in the cylinder,
the conductivity of the water is too high or it isn't decanted often
enough. In this case please contact HygroMatik.
