RPC Operational Connections
Description Wire No Voltage Type Contact
Remote Controls On
6027, 5024A 24VDC Momentary, Normally Open (NO)
Remote E-Stop 5024A, 5024B 24VDC Normally Closed (NC)
Remote Pump On 6028, 24VDC 24VDC PLC Input, Momentary, NO
Remote Pump Off 6029, 24VDC 24VDC PLC Input, Momentary, NC
RPC Status Connections
Description Wire No Voltage Type Contact
Remote Controls On
6027, 5024A 24VDC Momentary, Normally Open (NO)
Remote E-Stop 5024A, 5024B 24VDC Normally Closed (NC)
Remote Pump On 6028, 24VDC 24VDC PLC Input, Momentary, NO
Remote Pump Off 6029, 24VDC 24VDC PLC Input, Momentary, NC
RPC Emergency Stop Connections
Description Wire No Voltage Type Contact
Remote Cooling Mode 6030, 24VDC 24VDC PLC Input, Momentary or Maintained, NO
Discrete Pressure Input 6022, 6022A 24VDC PLC Input, Maintained, NO
Controls On Indicator 5024C, 24COM 24VDC PLC Output
Remote Mode Active Indicator 6027, 24COM 24VDC PLC Output
Remote Pump Fault Indicator 7004, 24COM 24VDC PLC Output
Remote Pump Run Indicator 6047, 24COM 24VDC PLC Output
1
Optionally you can require the operator to turn the key switch to LOCAL mode, press the CONTROLS ON button, then
turn the key switch back to REMOTE. When doing it this way any time a fault shutdown or E-Stop occurs you will need
to turn the controls on this way at the pump.
