4-14
Service Manual
PARTS LIST
Note: See Section 5 Parts List 400V CE for parts and components of the 400V CE Powermax800 system.
9-96
RECOMMENDED SPARE PARTS - POWERMAX800- 208/240/480V
Part Number Description Page Reference
003078 ........................................... Relay:30A NO Mag Blwt QDisc Term ........................................................ 4-5
129068 ........................................... Circuit Breaker SA:4Pole 480V W/TC ........................................................ 4-9
129151 ........................................... Contactor SA:Powermax800 ...................................................................... 4-9
008809 ........................................... Fuse:1A 600V 13/32X1-1/2Slo (2) ............................................................. 4-4
014207 ........................................... Xfmr:Powermax800 208-240-480 Control .................................................. 4-7
014210 ........................................... Xfmr:Powermax800 208-240-480 Power ................................................... 4-7
014186 ........................................... Inductor:Powermax800 2MH 50A .............................................................. 4-7
023922 ........................................... Cable w/Clamp:PMX800 Work 20' ............................................................. 4-3
027080 ........................................... Fan:225CFM 120VAC 50-60HZ ................................................................. 4-7
005112 ........................................... Pressure Switch:39 Psi .013 Orifice ........................................................... 4-3
006054 ........................................... Sol. Valve:100# 1/8FPT 24VAC NC ........................................................... 4-3
011072 ........................................... Filter:20 Micron 1/8FPT .............................................................................. 4-9
011079 ........................................... Filter Element for 011072 Filter .................................................................. 4-9
011073 ........................................... Regulator:0-125 Psig 1/8FPT ..................................................................... 4-3
022027 ........................................... Press. Gauge:160# 1.5" 1/8CBM Panel ..................................................... 4-3
029957 ........................................... Heatsink SA:Powermax800 Power Unit ..................................................... 4-5
109018/008906 .............................. Diode:600V 100A UFast Recovery Dual (2)/Thermal Pad:AL-380-100 (2) 4-5
109019/008904 .............................. Diode:1600V 100A 3PH Module/Thermal Pad:AL-340-180 ....................... 4-5
005178 ........................................... Temp. Switch Opens 85°/Closes 75°C ...................................................... 4-5
009849/008903 .............................. Resistor:20-Ohm 50W 5% NON-IND (4)/Thermal Pad: AL 197-114 (4) .... 4-5
009850/008902 .............................. Resistor:20-Ohm 25W 5% NON-IND (4)/Thermal Pad:AL 103-108 (4) ..... 4-5
009918 ........................................... Capacitor:.012UF 1000WV 10% Poly (4) ................................................... 4-5
009968 ........................................... Capacitor:.6800PF 1000WV 10% Poly (4) ................................................. 4-5
029998/008905 .............................. IGBT Gate Drive SA:Powermax800 (2)/Thermal Pad:AL-370-134 (2) ....... 4-5
041472 ........................................... PCB Assy:Powermax800 Control............................................................... 4-5
041532 ........................................... PCB Assy:Powermax800-ZB Power .......................................................... 4-5, 4-7
129114 ........................................... Cord/Plug:42 1Phase 8-3SO 3Prong 7'3" .................................................. 4-9
029674 ........................................... MOV/Cap Assy:MAX42/43/70 3PH ............................................................ 4-5
028908 ........................................... Kit:Powermax800 Cooling Fan Filter .......................................................... 4-7
RECOMMENDED SPARE PARTS - POWERMAX800- 200/230/400V
Part Number Description Page Reference
003078 ........................................... Relay:30A NO Mag Blwt QDisc Term ........................................................ 4-5
129068 ........................................... Circuit Breaker SA:4Pole 480V W/TC ........................................................ 4-9
129151 ........................................... Contactor SA:Powermax800 ...................................................................... 4-9
008958 ........................................... Fuse:1A 500V 10mmX38mm SLO (2)........................................................ 4-4
014208 ........................................... Xfmr:Powermax800 200-230-400 Control .................................................. 4-7
014211 ........................................... Xfmr:Powermax800 200-230-400 Power ................................................... 4-7
014186 ........................................... Inductor:Powermax800 2MH 50A .............................................................. 4-7
023922 ........................................... Cable w/Clamp:PMX800 Work 20' ............................................................. 4-3
027443 ........................................... Fan:260CDM 120VAC 50-60HZ................................................................. 4-7
005112 ........................................... Pressure Switch:39 Psi .013 Orifice ........................................................... 4-3
006054 ........................................... Sol. Valve:100# 1/8FPT 24VAC NC ........................................................... 4-3
011072 ........................................... Filter:20 Micron 1/8FPT .............................................................................. 4-9
011079 ........................................... Filter Element for 011072 Filter .................................................................. 4-9
011073 ........................................... Regulator:0-125 Psig 1/8FPT ..................................................................... 4-3
022027 ........................................... Press. Gauge:160# 1.5" 1/8CBM Panel ..................................................... 4-3
029957 ........................................... Heatsink SA:Powermax800 Power Unit ..................................................... 4-5
109018/008906 .............................. Diode:600V 100A UFast Recovery Dual (2)/Thermal Pad:AL-380-100 (2) 4-5
109019/008904 .............................. Diode:1600V 100A 3PH Module/Thermal Pad:AL-340-180 ....................... 4-5
005178 ........................................... Temp. Switch Opens 85°/Closes 75°C ...................................................... 4-5
009849/008903 .............................. Resistor:20-Ohm 50W 5% NON-IND (4)/Thermal Pad: AL 197-114 (4) .... 4-5
009850/008902 .............................. Resistor:20-Ohm 25W 5% NON-IND (4)/Thermal Pad:AL 103-108 (4) ..... 4-5
009918 ........................................... Capacitor:.012UF 1000WV 10% Poly (4) ................................................... 4-5
009968 ........................................... Capacitor:.6800PF 1000WV 10% Poly (4) ................................................. 4-5
029998/008905 .............................. IGBT Gate Drive SA:Powermax800 (2)/Thermal Pad:AL-370-134 (2) ....... 4-5
041517 ........................................... PCB Assy:Powermax800 Control............................................................... 4-5
041532 ........................................... PCB Assy:Powermax800-ZB Power .......................................................... 4-5, 4-7
129115 ........................................... Cord: 2.5mm PVC HD21/22 ....................................................................... 4-9
029674 ........................................... MOV/Cap Assy:MAX42/43/70 3PH ............................................................ 4-5
028908 ........................................... Kit:Powermax800 Cooling Fan Filter .......................................................... 4-7
