Hypertherm powermax1650 - Torch Installataion

MAINTENANCE
powermax1650 Service Manual
3-21
0
Torch Installation

Turn OFF power.

Remove power cord from power receptacle.

Open Easy Torch Removal (ETR) door and route lead through the end cap.
OFF
ON
_
+
4
.
0
5.
0
5
0
60
A
C
7
0
80
V
B
A
R
6
.
0
P
S
I
A
MP
S
3
0
4
0
1
0
0
8
0
6
0
ETR
Door
End Cap
