Hypertherm powermax1650 Service Manual

PARTS – TORCH AND CONSUMABLES
powermax1650 Service Manual
5-7
0
Torch Consumable Configurations
Mechanized, ShieldedUnshielded**
120930 120932120928*
220047 220011220048*
100A
40A
O-Ring
058519
120930 120931120928*
60A
220051220037
120930 120927120928*
80A
120925120926
120979 220064220048
100A
120979 220006120928
40A
O-Ring
058519
120979 120980120928
80A
120979 220007120928
60A
220051220037
120925120926
* Use an ohmic sensing cap when a
compatible torch height contoller is
installed.
** In CE countries, unshielded
consumables may only be used in
mechanized torch applications.
Maintain torch-to-work distance of
approximately 3/16 inch (4.8 mm).
220061*
Shield NozzleRetaining Cap
Swirl RingElectrode
220206*
Ohmic Sensing
Retaining Cap
100A40A-80A
