Parts
powermax
65/85
Operator Manual 6-7
Duramax 15° hand torch replacement parts
Torch handle
Torch lead
Handle
screws
Safety trigger
and spring
O-ring
Torch head
Pilot terminal
screw
Cap-sensor
switch
Part number Description
059470 Powermax65/85/105 15° hand torch assembly with 7.6 m (25 ft) lead
059471 Powermax65/85/105 15° hand torch assembly with 15 m (50 ft) lead
059472 Powermax65/85/105 15° hand torch assembly with 23 m (75 ft) lead
228955 Kit: Duramax 15°/HRTs torch handle replacement
075714 Handle screws, #4 x 1/2 slotted TORX pan head, S/B
228721 Kit: Duramax 75°/15° hand torch safety trigger with spring replacement
228715 Kit: Duramax 15° hand torch main body replacement (torches built before May 2012)
228957 Kit: Duramax 15° hand torch main body replacement (torches built after May 2012)
058519 O-ring: VITON .673 X .063
075504 Pilot terminal screw: MSCR:4-40 X 5/16 SW CN SEM PH PAN S/Z
228109 Kit: Powermax30/45/65/85/105 15° hand torch/T30v/T45v/HRTs cap-sensor switch
replacement
228959 Kit: Duramax hand torch lead replacement, 7.6 m (25 ft)
228960 Kit: Duramax hand torch lead replacement, 15 m (50 ft)
228961 Kit: Duramax hand torch lead replacement, 23 m (75 ft)
128642 Kit: Trigger start switch replacement
The entire hand torch and lead assembly can be replaced, or individual component parts can be replaced. Part numbers
starting with 059 indicate complete torch and lead assemblies.
