HYPERVOLT Home 3.0 - Connecting the LED Plate

12
Connecting the LED Plate
Installation
STEP 7
Once you have finished wiring your Hypervolt charger, you will need to re-fit the LED plate (B). First click together the white square cable joint. Put the top two
tabs of part (B) over their locators on the top side of the back box (A). Now pull down on the middle bottom edge of part (B) and click the bottom into place. Take
care not to trap any cabling between parts A & B. Run you hands all around the edges of the back box and LED Plate to confirm all the tabs are flat and square.
