2. TECHNICAL SPECIFICATIONS
Table 2. Operating environmental conditions (indoors) for Device
CONDITIONS
VALUE
Air temperature range
From 0°C to 35°C+
Relative humidity
Up to 75%
Table 3. Basic technical specifications of Device
PARAMETERS DESCRIPTION
VALUE
Maximum image size (diameter)
567mm
Diameter
567mm
Depth
174mm
Number of rays
4
Rotation speed
670RPM
Number of LEDs per each ray
168
Input voltage
100-240V
Current
1.0A
Input AC frequency
50/60Hz
Net weight
2.8kg
Noise figure on the Device axis
(1 m from the Device)
45Db
Fuse
Ceramic 4A 250VAC 5X20mm
Power cable length
3m
Power cable thickness
8mm (max)
