www.hysecurity.com General Maintenance D0559 Rev. A 89
Drive Wheel Assembly
Drive wheel assembly tasks are slightly different depending on the type: AdvanceDrive™ or XtremeDrive™.
NOTE: Installation instructions are provided with the replacement drive wheels. However, a brief overview of the
drive wheel assembly is shown below.
Collared Drive Wheels AdvanceDrive Wheels
AdvanceDrive Wheels assembled AdvanceDrive and XtremeDrive Wheel combo
