Hysolis Apollo 5K - Page 16

14
12V/24V
MAX
10A
·
DC INPUT
MAX
35A
·
AC INPUT
COM1
AC OUTPUT
COMM.PORT
COM2
RESET
RUN
ALM
CHARGE
I
n
v
e
r
t
e
r
R
e
s
e
t
S
w
i
t
c
h
A
C
I
n
p
u
t
R
e
s
e
t
S
w
i
t
c
h
BATTERY
1
51.2VDC
BATTERY
2
51.2VDC
120V~450V
MAX.4000W(18A)
SOLAR INPUT
ONLY CONNECT HYSOLIS 5K BATTERIES.
DO NOT USE 3RD-PARTY BATTERIES.
CONNECTING THE WRONG BATTERY
MAY DAMAGE THE UNIT AND/OR HARM
THE USER.
CAUTION!
SWITCH BATTERIES OFF
BEFORE CONNECTING OR
DISCONNECTING BATTERY
CABLES.
CAUTION!
VOLTAGE MAY BE PRESENT ON
PV INPUT WHEN INVERTER IS
OPERATING..
DANGER!
Battery
Switch
DISCONNECT ALL INPUT AND
OUTPUT CABLES BEFORE
SWITCHING ON OR OFF.
BATTERY MAY ALWAYS BE
LEFT ON EXCEPT FOR
SHIPPING OR STORAGE.
NOTICE!
Panel 1
Panel 2
Panel 3 Panel N
5.3.5 Single Unit: PV (solar) Input
Fig. 5.8 Single unit - PV input port and cable (N panels)
Solar MPPT Voltage Range 120VDC~500VDC
Maximum Solar Charging Power 4,400 watts
Maximum Solar Input Current 18A
Maximum Solar Input Power 5,000 watts*
Maximum MPPT Charge Current DC 80A
Table 5.5 PV input power parameters
N panels in series
(Note: always configure
your array within the
MPPT specifications
(Table 5.5)
* When Inverter is Active, some Solar Input Power may be
used for Inverter Power
