Hysolis Apollo 5K - 4.3 Back Panel

5
12V/24V
MAX
10A
·
DC INPUT
MAX
35A
·
AC INPUT
COM1
AC OUTPUT
COMM.PORT
COM2
RESET
RUN
ALM
CHARGE
I
n
v
e
r
t
e
r
R
e
s
e
t
S
w
i
t
c
h
A
C
I
n
p
u
t
R
e
s
e
t
S
w
i
t
c
h
BATTERY
1
51.2VDC
BATTERY
2
51.2VDC
120V~450V
MAX.4400W(18A)
SOLAR INPUT
ONLY CONNECT HYSOLIS 5K BATTERIES.
DO NOT USE 3RD-PARTY BATTERIES.
CONNECTING THE WRONG BATTERY
MAY DAMAGE THE UNIT AND/OR HARM
THE USER.
CAUTION!
SWITCH BATTERIES OFF
BEFORE CONNECTING OR
DISCONNECTING BATTERY
CABLES.
CAUTION!
VOLTAGE MAY BE PRESENT ON
PV INPUT WHEN INVERTER IS
OPERATING..
DANGER!
Battery
Switch
DISCONNECT ALL INPUT AND
OUTPUT CABLES BEFORE
SWITCHING ON OR OFF.
BATTERY MAY ALWAYS BE
LEFT ON EXCEPT FOR
SHIPPING OR STORAGE.
NOTICE!
Fig. 4.3 • Unit back panel
4.3 Back Panel
11. 120V AC Input Port
LP-28 (MAX 30A)
12. Inverter Reset Switch
13. AC Output parallel
communication port
(For AC output parallel
set up)
14. Expansion Battery
Port 1
15. Expansion Battery
Port 2
16. AC Input Reset Switch
17. 12/24VDC Input Port
(Max. 10A)
18. Power Switch
(for Battery BMS)
19. Solar Input Port
(Voc. Range 120V DC ~
500V DC,
Max. Charging Power
4,400W,
Max. Total Input for
Charging+Inverter
5,000W/18A)
20. BMS Working Status
Indicator
21. Ground Port
22. BMS Reset Button
11
12
13
14
16
17
18
22
15
19
21
20
