No. Ref. No. Print No. Part No. Description
839 R9025 T3C 3001052710010 270Ω
840 R9027 T1D 3001058220000 8.2KΩ
841 R9028 T3C 3001052710010 270Ω
842 R9029 T1D 3001053310000 330Ω
843 R9033 B1C 3001051020000 1KΩ
844 R9036 B1F 3001051030000 10KΩ
845 R9038 B1E 3001051020000 1KΩ
846 R9039 B1F 3001051010000 100Ω
847 R9041 B1F 3001054720000 4.7KΩ
848 R9043 B1E 3001053320000 3.3KΩ
849 R9045 B1D 3001051050000 1MΩ
850 R9046 B1E 3001054740010 470KΩ
851 R9047 B1E 3001053330000 33KΩ
852 R9048 B1D 3001051540000 150KΩ
853 R9050 B1E 3001054730000 47KΩ
854 R9053 B1D 3099080398010 0.39Ω
855 R9054 B1D 3099080398010 0.39Ω
856 R9055 B1D 3099080398010 0.39Ω
857 R9057 B1D 3001051540000 150KΩ
858 R9058 B1E 3001051050000 1MΩ
859 R9059 B1E 3001051040000 100KΩ
