No. Ref. No. Print No. Part No. Description
860 R9003 T4E 3001052710010 270Ω
861 R9004 T3C 3233099449000 4.4nH
862 R9005 T4E 3001055690000 5.6Ω
863 R9006 T2B 3001051030000 10KΩ
864 R9007 T2F 3001058200000 82Ω
865 R9008 T1E 3001051520000 1.5KΩ
866 R9009 T1E 3001053300000 33Ω
867 R9011 T2F 3001051010000 100Ω
868 R9012 T2E 3001051010000 100Ω
869 R9013 T2F 3001053320000 3.3KΩ
870 R9015 T1E 3001053310000 330Ω
871 R9016 T1E 3001051510000 150Ω
872 R9017 T1D 3001051010000 100Ω
873 R9018 T1E 3001056810000 680Ω
874 R9019 B2F 3001054720000 4.7KΩ
875 R9020 B1F 3001051030010 10KΩ
876 R9021 T1F 3001054700000 47Ω
877 R9022 T1F 3001052200000 22Ω
878 R9023 T1E 3001053920010 3.9KΩ
879 R9024 T1D 3001056820000 6.8KΩ
880 R9025 T3C 3001052710010 270Ω
