Service Manual UHF5 (806-941MHz) Information
361
No. Ref. No. Print No. Part No. Description
566 D601 B3E 3399990000110 Diode
567 D602 B3E 3399040600020 ESD protection diode
568 D604 B4D 3303030100010 Switching diode
569 D9002 T3C 3303030800040 Switching diode
570 D9005 T3C 3303990000060 Switching diode
571 D9006 T4C 3399990000260 Rectifier diode
572 D9008 T3C 3303990000060 Switching diode
573 D9010 B1E 3302031100010 Zener diode
574 E / 6201860000010 Shielding frame for GPS
575 F601 B3E 4099000000050 Fuse
576 F602 T5J 4010000000010 Resumable fuse
577 G / 6202784000000 Shielding frame for low VCO
578 H / 6201865000000 Shielding can for crystal oscillator
579 I / 6201810000000 Shielding can for baseband processor
580 J1601 B3K 5201050100030 Board-to-board connector
581 J311 B4F 5201030200010 Board-to-board connector
582 J313 B4B 5202002100200 Board-to-wire connector
583 J601 T3D 5205003100020 Battery connector
584 J821 B4C 5201016000010 Board-to-board connector
585 K / 6202783000000 Shielding frame for buffer
586 L101 T1F 3217105569010 5.6nH
