Service Manual VHF (136-174MHz) Information
477
No. Ref. No. Print No. Part No. Description
1007 U821 T2K 3613010000000 Baseband processor
1008 U9002 B1E 3605025000020 Operational amplifier
1009 U9003 B1D 5404000000060 Temperature sensor
1010 X101 T1I 3701019250030 VC-TCXO
1011 X201 B5J 3701327610060 Crystal
1012 X203 B3H 3701019250040 TCXO
1013 Z501 B3C 3804157560000 GPS filter
1014 Z9001 B3F 3802448540040 Crystal filter
1015 / / 6201809000000 Shielding can for IF processor
1016 / / 6201810000000 Shielding can for baseband processor
1017 / / 6201859000000 Shielding can for low-pass filter
1018 / / 6201860000000 Shielding can for GPS
1019 / / 6201862000000 Shielding can for TX VCO
1020 / / 6201865000000 Shielding can for crystal oscillator
1021 / / 6201915000000 Shielding can for antenna spring plate
1022 / / 6201935000000 Shielding can for switching power
1023 / / / Main board
PD70X/ PD70XG/ HD705/ HD705G Channel Board
No. Ref. No. Part No. Description
1 R1002 3001051210010 120Ω
