Hytera HD705 - 12.3 Assembly

Service Manual VHF (136-174MHz) Information
479
No. Ref. No. Part No. Description
26 J1001 5201016100040
Board-to-board connector
27 S1003 4301080000020
Momentary contact switch
28 / 41PD7002002B0 PCB
29 R1001 3001056810000 680Ω
30 C1015 3101051040060 0.1UF
31 C1016 3101051040060 0.1UF
32 C1017 3101051040060 0.1UF
33 L1001 3221506181000
Bead
34 U1002 3608006000030
Power management IC
PD78X/ PD78XG/ HD785/ HD785G Channel Board
No. Ref. No. Part No. Description
1 R1002 3001051210010 120Ω
2 C1001 3101052710000 270PF
3 C1002 3101052710000 270PF
4 C1003 3101052710000 270PF
5 C1004 3101052710000 270PF
6 C1005 3101052710000 270PF
7 C1006 3101052710000 270PF
8 C1007 3101052710000 270PF
9 C1010 3101052710000 270PF
10 C1011 3101052710000 270PF
11 C1012 3101052710000 270PF
