3
2.2 Rear Panel
No. Part Name No. Part Name
1
RF Antenna Connector (BNC
female)
3 Accessory connector
2 Power Inlet 4
GPS Antenna Connector
(SMA
female)
Note: The GPS antenna connector is only available for MD78XG Mobile Radio.
2.3 Programmable Keys
For enhanced convenience, you may request your dealer to program the seven keys (TK( ), P1, P2,
P3, P4, P5(
) and P6( )) as shortcuts to the functions introduced in the Owner’s Manual. Please
refer to the corresponding Feature Book for more details.
Caution: The TK is programmed with emergency feature by default (short press: Emergency On;
long press: Emergency Off). It is programmable by your dealer. Short press of the P5 key is programmed
with the Contact List feature, and short press of the P6 key programmed with the Home Screen feature.
To Next Page
