Assembly and Disassembly
Attaching/Removing the Belt Clip
Attaching the Belt Clip
Align the two screw holes on the metal bracket of the belt clip with holes on the
elliptical protrusion on the back side of the radio. Then secure the belt clip on
the back side of the radio, as shown in Figure 6. Align the belt clip screws with
screw holes on the metal bracket of the belt clip, and then secure the screws.
Removing the Antenna
Turn the antenna counter-clockwise until you can remove it.
Removing the Belt Clip
Loosen the screw to remove the belt clip. Please refer to the operations for
attaching the belt clip.
Fig.5
Fig.6
