LITHIUM SERIES® Electric Torque Tool (BTM and BTM-DOC Models) Operations Manual
6
The LITHIUM SERIES® Electric Torque Tool provides the following:
• High-strength planetary gear drive powered by brushed DC electric motor.
• Two Speeds: Fast run-down, high powered torque.
• Electronic control and setup via push-button menu.
• Heads-Up LCD display.
• Ergonomic lightweight hand-held design with pistol-grip and trigger activation.
• Portable tool powered by rechargeable extended-life 36V lithium ion battery.
• Standard square-drive with dual-reaction spline.
• Integrated data acquisition and export capability.
PUSH-BUTTON CONTROL PANEL
. TOOL DESCRIPTION
Eyelet
Brushless DC Motor
Cooling Vents
Square Drive
Reaction Spline
Trigger
Pistol Grip Handle
Battery Lock Button
Battery Test Button
and Charge
36V Rechargable and
Interchangeable Battery
USB Port
Planetary Gear Box
Dual Speed Switch
