2-10
22D9TRE18
Mounting bolts holding to flywheel
Mounting bolts holding to flywheel
housing
Remove transmission assembly from the
engine flywheel housing by loosening the
8 mounting bolts.
(8)
①
22D9TRE17
Torque converter
Remove the cover on top face of the
torque converter housing then remove
the 8 mounting bolts installed on the
engine flywheel. To rotate the flywheel,
remove 1 mounting bolt, then insert a
turning tool in the mounting hole. One
man must turn the engine fan by hand
while the other turns the flywheel.
(7)
①
Using a moving truck slowly pull out
transmission assembly to the front.
②
20DTRE19
