2-11
INSTALLATION
INSTALLATION
Installation is the reverse order to removal,
but be careful of the following points.
Tightening torque
· Bolt (1):5.9~8.9 kgf · m (42.7~64.3 lbf · ft )
· Bolt (2):2.7~4.1 kgf · m (19.5~29.7 lbf · ft )
· Bolt (3):5.9~8.9 kgf · m (42.7~64.3 lbf · ft )
· Bolt (4):62~68 kgf · m (448~491 lbf · ft )
· Bolt (5):7.5 kgf · m (54.2 lbf · ft )
(1)
(2)
2)
2)
Bolt (1)
Bolt (4)
Bolt (2)
Bolt (5)
Bolt (3)
22D9TRE21
