N700E INSTRUCTION MANUAL
1-11
1.4.5 N700E-300HF/370HFP ~ N700E-1320HF/1600HFP
Figure 1-5: Front View with/without Front Cover: 370HF ~ 1320HF
1.4.6 N700E-1600HF/2000HFP ~ N700E-2200HF/2500HFP
Figure 1-6: Front View with/without Front Cover: 1600HF ~ 1320HF
Front
Cover
Operator
Operator
Front Cover
Control circuit
terminals
Control circuit
terminals
Main circuit
terminals
Main circuit
terminals
