4. Wiring
4.1 Overall Configuration
The following diagram shows an example of configuration to build a CC-Link by using a gateway unit.
Host system (PLC master station)
Terminal resistor
Slave station
Gateway unit
Teaching box
Terminal
resistor
4-direction junction
SIO communication network
Terminal resistor
24V
power
supply
