8.3. Master PLC address assignment
The basic concept of address assignment (memory map) for the CC-Link master PLC has been explained in
5.2. This section explains a case when the gateway unit is a remote station. If the gateway unit is a remote
device station (remote station which handles bit information and word information), the number of exclusive
stations depends on the operation mode.
Input and output region
Operation mode
Remote I/O
Remote
register
Number of exclusive
stations
Number of
controlled axes
Position data limit designation 8 word 16 word 4 14
Position No. designation 8 word 16 word 4 14
Normal position data designation 8 word 16 word 4 7
Push operation data designation 8 word 16 word 4 3
Small 10 word 24 word * Depends on setting 16 max.
Middle 20 word 48 word * Depends on setting
16 max.
Simple direct
value/Position No.
designation
Large 24 word 64 word * Depends on setting
16 max.
* Number of links per one CC-Link remote station is 32 points (two words) for remote input and output, and
four points (four words) respectively for remote register, then a maximum 64 stations per one system can be
linked.
Number of links per one station can be expanded by the expanded cyclic setting.
