For an example of the CC-Link setting in GX Developer V8, refer to the 9.5.2 (2).
Number of exclusive stations, expanded cyclic setting and size of data area are as shown in the table below.
CC-Link version Ver. 1 Ver. 2
Direct value designation
○ × × ×
POS designation
○ × × ×
Direct value/speed/acceleration and deceleration designation
○ × × ×
Direct value/speed/acceleration and deceleration/positioning
width/push %
○ × × ×
Simple direct value/Position No. designation Small
× ○ × ×
Simple direct value/Position No. designation Middle
× × ○ ×
Simple direct value/Position No. designation Large
× × × ○
Number of exclusive stations 4 3 3 2
Expanded cyclic setting - 2 4 8
Bit data (byte) 16 20 40 48 Size
Word data (byte) 32 48 96 128
