13
Tech Support: (877) 591-2491
Repositioning the socket plate (arm): Loosen the wing
nut just enough to push the plate (arm) as far into the
enclosure as it will go. Retighten the wing nut. Retest
your LightSpeaker
®
for proper fit. If it fits, remove it again
and go forward to Step 7.
Complete removal of the socket plate: Loosen the wing
nut, turning the “wings” so that they are aligned with the
slot. Slide the plate until the big opening in the slot aligns
with the thick part of the wing nut. Lift the socket plate
free of the wing nut. Slide the wing nut up to the top of
the slot and retighten.
The Edison socket is most often attached to the socket
arm with either 2 screws or via a spring bracket. Either
remove the screws to free the socket, or pinch the spring
bracket to slide it free of the plate (arm). In 5” fixtures
this spring bracket may be attached to a metal bracket
which is itself attached to the trim ring and reflector.
