7 Device description
7.1 Device view
Operating state display
Rotary switch S2
Fiber optic input (RX) X11
Voltage supply X14
Fiber optic output (TX) X10
Push button S10 (Reset)
PROFINET device 0 X40 (2-port switch)
PROFINET device 1 X41 (2-port switch)
TAP interface X42 (sniffer)
Figure 1: Front view
Shield connector X29
Monitor interface X13 (Ethernet)
Service interface X12 (Ethernet)
Figure 2: Bottom view
