IBC SL 26-260 G3 Installation And Operating Instructions

6-3
DIAGRAMS
SL 26-260 G3, SL 40-399 G3 MODULATING GAS BOILERS
Table : Boiler assembly parts list
(refer to Diagram
Some parts are available only in
Kits. Please visit www.ibcboiler.
com for more information.
ITEM PART NUMBER DESCRIPTION QTY
10 240-113 FAN 1
20 150-073 MIXER O-RING 1
30 180-161 FUEL MIXER, NG 1
180-162 FUEL MIXER, LP
40 250-742 GASKET, GAS VALVE COUPLER 1
50 250-768 GAS VALVE COUPLER 1
60 250-741 NUT, GAS VALVE COUPLER 1
70 180-166 GAS VALVE 1
80 190-157 GAS LINE 1
90 190-162 AIR INTAKE ASSEMBLY 1
100 250-859 AIR INTAKE ASSEMBLY, MOUNTING CLIP 1
110 250-322 GASKET, FAN TO LID 1
120 250-050 GASKET, IGNITOR 1
130 240-002 IGNITOR 1
140 250-057 SIGHT GLASS HOUSING 1
150 255-025 GASKET, HOUSING-GLASS 1
160 250-059 SIGHT GLASS 1
170 255-023 GASKET, SIGHT GLASS-H.Ex. 1
180 255-026 GASKET, H.Ex. LID-H.Ex. 1
190 255-034 GASKET, BURNER-H.Ex. 1
200 180-186 BURNER 1
210 250-761 HEAT EXCHANGER REFRACTORY 1
220 500-044 V10.0 CONTROL MODULE 1
230 250-488 CONTROLLER, TERMINAL BLOCK COVER 1
240 500-021 DOOR ASSEMBLY 1
250 240-006 PRESSURE SENSOR, RETURN WATER 1
260 250-258 RETURN WATER PIPE 1
270 250-682 WATER PIPE SPACER 1
280 255-024 GASKET, WATER PIPE 2
290 180-013 CONDENSATE TRAP 1
300 250-664 CONDENSATE TRAP RETAINER 1
310 240-134 TEMPERATURE SENSOR, RETURN WATER 1
320 240-133 TEMPERATURE SENSOR, SUPPLY WATER 1
330 170-032 HEAT EXCHANGER 1
340 250-259 SUPPLY WATER PIPE 1
350 240-010 LOW WATER CUT OFF PROBE 1
360 180-005 PRESSURE RELIEF VALVE 1
370 250-187 RATING LABEL, PANEL 1
380 250-254 BRACKET, VESSEL LIMIT SWITCH 1
390 240-030 VESSEL TEMP. HIGH LIMIT SWITCH 1
