IBC SL 26-260 G3 Installation And Operating Instructions

6-7
DIAGRAMS
SL 26-260 G3, SL 40-399 G3 MODULATING GAS BOILERS
Table : Boiler assembly parts list
(refer to Diagram 6.1-2 on opposite
page)
Some parts are available only in
Kits. Please visit www.ibcboiler.
com for more information.
ITEM PART # DESCRIPTION QTY
10 240-113 FAN 1
20 150-073 MIXER, NG 1
180-164 MIXER, LP
30 150-232 MIXER O-RING 1
40 190-160 GAS VALVE ELBOW 1
50 150-259 GAS VALVE ELBOW O-RING 1
60 250-869 NATURAL GAS ORIFICE 12.0 1
250-865 PROPANE ORIFICE 11.2
70 255-035 ORIFICE/COUPLER GASKET 2
80 180-150 GAS VALVE 1
90 250-755 GAS INLET BLOCK 1
100 150-001 GAS INLET BLOCK O-RING 1
110 250-794 GAS VALVE COUPLER ROTATION LOCK 1
120 250-793 GAS VALVE COUPLER BOTTOM PLATE 1
130 190-162 AIR INTAKE ASSEMBLY 1
140 250-859 AIR INTAKE MOUNTING CLIP 1
150 190-158 GAS LINE 1
160 250-322 FAN GASKET 1
170 240-002 IGNITER 1
180 250-050 IGNITER GASKET 1
190 250-057 SIGHT GLASS FRAME 1
200 255-023 SIGHT GLASS LOWER GASKET 1
210 250-059 SIGHT GLASS 1
220 255-025 SIGHT GLASS UPPER GASKET 1
230 255-048 BURNER GASKET 1
240 255-009 HEAT EXCHANGER LID GASKET 1
250 180-185 BURNER 1
260 250-753 HEAT EXCHANGER REFRACTORY 1
270 500-044 V10.0 CONTROL MODULE 1
280 250-488 CONTROLLER TERMINAL BLOCK COVER 1
290 500-079 DOOR ASSEMBLY 1
300 240-006 RETURN WATER PRESSURE SENSOR 1
310 250-748 RETURN WATER PIPE ASSEMBLY 1
320 255-027 GASKET, WATER PIPE 2
330 240-133
TEMPERATURE SENSOR, SUPPLY
WATER
1
340 240-134
TEMPERATURE SENSOR, RETURN
WATER
1
350 180-065 CONDENSATE TRAP 1
360 250-664 CONDENSATE TRAP RETAINER 1
370 HEAT EXCHANGER 1
