36 IBM Rack Console Switch Installation and User’s Guide
Figure 3.10: Flag window
Determining the display of the status flag
1. Access the Flag window. If needed, see “Accessing the Flag window” on page 35.
2. Select Name or
eID.
3. Select Displayed to show the flag all the time or select Timed to display the flag for only five
seconds after switching.
4. Select a flag color in the Display Color area.
5. In the Display Mode area, select Opaque for a solid color flag or select Transparent to see
the desktop through the flag.
6. To position the status flag on the desktop:
a. Click Set Position to gain access to the Set Position window.
b. Left-click the title bar and drag to the desired location.
c. Right-click to return to the Flag window.
Figure 3.11: Set position window
NOTE: Changes made to the flag position are not saved until you click OK in the Flag window.
7. Click OK in the Flag window to save the changes.
-or-
Click X or press Esc
to exit the window without saving changes.
