62 IBM Rack Console Switch Installation and User’s Guide
Appendix B: Technical Specifications
Table B.1: Rack console switch product specifications
Product Specifications
Server Ports
Number
8 (1 x 8 rack console switch), 16 (2 x 16 rack console switch)
Cable Types
USB and PS/2
Connectors
RJ-45
Sync Types
Separate horizontal and vertical
Plug and Play
DDC2B
Video Resolution
Local Port Maximum 1280 x 1024 @ 75 Hz
Up
date Port
Number
1
Type
Serial RS-232
Connector
DB-9 Female
Lo
cal Port Sets
Number
1 (1 x 8 rack console switch), 2 (2 x 16 rack console switch)
Type
PS/2, VGA, USB, and ACI (ACI port available only for User A)
Connectors
2 PS/2 MiniDIN 6, 2 USB Type A, 1 HD15
Dim
ensions
Dimensions (H x W x D)
4.45 cm x 43.18 cm x 27.94 cm 1 U form factor (1.75 in x 17.00 in x 11.00 in)
Weight
3.6 kg (8 lb) without cables
Heat Dissipation
92 Btu/Hr
Airflow
8 CFM
Power Consumption
12.5 Watts
AC-input power
40 Watts maximum
AC-input voltage rating
100 to 240 V ac Autosensing
AC-input current rating
0.5 A
AC-input cable
18 AWG three-wire cable, with a three-lead IEC-320 receptacle on the power
supply
end and a country or region dependent plug on the power resource end
AC-frequency
50 - 60 Hz
Temperature
0
o
to 50
o
C (32
o
to 122
o
F) operating
-30
o
to 60
o
C (-22
o
to 140
o
F) transit
-20
o
to 60
o
C (-4
o
to 140
o
F) storage
Humidity
20% to 80% noncondensing operating
5%
to 95% noncondensing nonoperating
Product Safety Standards
UL 60950-1, CSA C22.2 No. 60950-1, and EN 60950-1
