IBM 6400 Programmer's Reference

Device Control Command Set
Command set vectors contain information relating to each specific command set.
The format of each command set vector group follows:
Sense Type and Model
Device Control Command Set
Byte Description
0 01 (Acknowledgment Type)
1-4 Page/Copy Counters
5 FF (System/370 Convention)
6-7 Printer Product Number 4234.
8 Printer Model Number (See Note)
9-10 0000 (Reserved)
11-36 Device Control Command Set Vector
37-50 Text Command Set Vector
51-62 Image Command Set Vector
63-74 Graphics Command Set Vector
75-80 Page Segment Command Set Vector
81-88 Overlay Command Set Vector
89-94 Reserved
95-106 Bar Code Command Set Vector
Note: The format for byte 8, the printer model number, is:
11 - Model CTA NDS
12 - Model CTA AS/400
Table 16. Sense Type and Model
Byte Value Description
0 X'FF' System/370 convention
1-2 X'4234' Product Code
3 X'11'
X'12'
Model CTA NDS
Model CTA AS/400
4-5 X'0000' Reserved
Table 17 (Page 1 of 2). Device-Control Command Set
Byte Value Description
0-1 X'0016' Vector Length
2-3 X'C4C3' Device Control Command-Set ID
4-5 X'FF10' DC1 Subset ID
6-7 X'80F2' XOA Discard Buffered Data
8-9 X'80F4' XOA Request Resource List
10-11 X'80F6' XOA Exception Handling Control
12-13 X'80F8' XOA Print Quality
14-15 X'9005' XOH Erase Residual Print Data
Chapter 3. IPDS Commands Reference 43
