IBM 6400 Programmer's Reference

Device Control Command Set
Image and Coded-Font Self-Defining Field
Storage Pools Self-Defining Field
Table 31 (Page 2 of 2). Printable Area Self-Defining Field
Byte Value Description
10-11 X'13B0' -X'4C80' Width of the physical medium in L-units
(+Xm direction) Does NOT include
width of carrier strip for continuous
forms media.
12-13 X'000A' -X'7FFF' Length of the physical medium in L-units
(+Y direction)
14-15 X'0000' X Offset of the Printable Area in L-units
16-17 X'0000' Y Offset of the Printable Area in L-units
18-19 X'13B0' -X'4A40' X Extent of the Printable Area in L-units
20-21 X'000A' -X'7FFF' Y Extent of the Printable Area in L-units
22-23
Bit 0 0
Bits 1-2 01
Bit 3 1
Bit 4 0
Bit 5 0
Bit 6 0
Bits 7-15 000000000
Input Media Source Characteristics
0 = Simplex
01 = Continuous Forms
1 = Bin Available
0 = Retired
0 = No Envelopes
0 = Auto Media Feed
Reserved
Table 32. Image and Coded Font Resolution Self-Defining Field
Byte Value Description
0-1 X'000A' Length of this Self Defining Field
2-3 X'0003' Image and Coded Font Resolution Self
Defining Field
4 X'00' Unit Base 10 inches
5 X'00' Reserved
6-7 X'05A0' X Pels per Unit Base (1440 pels per 10
inches)
8-9 X'05A0' Y Pels per Unit Base (1440 pels per 10
inches)
Table 33. Storage Pools Self-Defining Field
Byte Value Description
0-1 X'000F' Length of this Self Defining Field
2-3 X'0004' Storage Pools Self Defining Field
4 X'0B' Length of each Storage Pool Self
Defining Field
5 X'01' Triplet ID
6 X'00' Storage Pool ID
7-10 X'00080000' Size of Storage Pool when empty (Bytes)
11-14 X'00000000' Reserved
Chapter 3. IPDS Commands Reference 53
