Chapter 4. Initializing the RackSwitch
When you supply power to the RackSwitch G8052, the switch initializes
automatically.
DANGER
Multiple power cords. The product might be equipped with multiple power
cords. To remove all hazardous voltages, disconnect all power cords.
(L003)
1
2
or
!
1
2
The following LEDs indicate the overall system status:
v Power Supply: Steady green if both power cords are connected, flashing green if
only one power cord is connected.
v Service(!):Offifthesystem is OK, flashing if service is required.
Use the mini-USB console cable to connect the RS-232 serial port on the switch
unit front panel to a terminal or a computer running a terminal emulation program.
You can access the command-line interface to perform initial configuration tasks.
To access the switch CLI and perform initial configuration tasks, use one of the
following methods:
© Copyright IBM Corp. 2013 47
