IBM NetVista Hardware Maintenance Guide

General Information 85
Repair Information
Removals and Replacements ..............................86
Handling ESD-Sensitive Parts .............................87
Cover..............................................................90
Bay Panels.....................................................92
Bay 1- 5.25-In. Bay
(Internal or External Access)..........................93
Bay 3 - 3.5-In. Bay
(Internal or External Access)..........................94
Bay 4 - 3.5-In. Bay
(External Access for Diskette Drive) ..............94
Front Panel.....................................................96
Power Supply.................................................97
Adapter Cards................................................98
Memory(DIMM) ..............................................99
AMD K7 Duron Processor............................100
System Backup Battery................................102
Indicator LED and Cable ..............................103
System Board...............................................104

IBM NetVista Specifications

General

Category	Desktop
Model	NetVista
Processor Type	Intel Celeron
Memory Type	SDRAM
Optical Drive	CD-ROM, DVD-ROM, or CD-RW
Graphics	Integrated Intel graphics
Audio	Integrated audio
Network	10/100 Ethernet
Operating System	Windows 2000, Windows XP (Varies by model)
Expansion Slots	PCI
Ports	USB, serial, parallel, VGA, audio in/out
