Parts Catalog 135
System Assembly
Assembly 1: System Unit
Asm-
Index
FRU
Number
Description
1-1 22P2260 Main Bezel (w/Front USB), Black
1-2 20L2197 3.5" FDD/HDD (Holder) Bracket
1-3 22P2256 Top Cover, Black
1-4 22P2257 Main Bezel Door, Black, NetVista
1-5 22P2258 Drive Bay Panel, Black
1-6 22P2261 Chassis Assembly, Lower Case
(without SPS) w/power supply frame,
drive frame, bracket port, w/ Front
USB
1-7 20L2190 Power Switch/HDD-Pwr Led Cable
Asm
1-8 19K3648 S21M - Micro ATX, Socket A, W/VIA
KZ133 (system board)
1-9 19K3649 Socket K7 Duron 64K/200 600MHz
1-9 19K3650 Socket K7 Duron 64K/200 700MHz
